Mindray uMEC12 Operator's Manual

C-10
Item Name
O.M
General User Defaults
C M
UAP, P3-P4 Venous Pressure Scale
Scale˄mmHg˅ * * 0-80
IBP Overlapping Left Scale
Scale (mmHg) * * 0-160
IBP Overlapping Right Scale
Scale (mmHg) * * 0-20
C.1.8 C.O. (for uMEC12/uMEC15)
Item Name
O.M
General User Defaults
C M
Alarm * * On
Alm Lev * * Med
TB High˄ºC˅ * * 39.0
TB Low˄ºC˅ * * 36.0
Comp. Const * * 0.542
Auto TI * * Auto
Manual TI˄ºC˅ * * 2.0
Measuring mode * * Manual
C.1.9 CO
2
(for uMEC12/uMEC15)
Item Name
O.M
General User Defaults
C M
Alarm * * On
Alm Lev * * Med
Operating Mode * * Measure
Sweep * * 6.25 mm/s
Scale˄mmHg˅ * * 50
Apnea Delay * *
Adu, Ped:
Neo:
20
15
RR Source * Auto

Mindray uMEC12 Specifications

General

Type	Patient Monitor
Display	12.1-inch color TFT
ECG	3-lead
SpO2	Yes
NIBP	Yes
Respiration	Yes
Temperature	Yes
Battery	Rechargeable lithium-ion
Networking	Ethernet
Parameters	ECG, SpO2, NIBP, Respiration, Temperature
Connectivity	Ethernet
Battery Life	Up to 4 hours
Power Supply	100-240 VAC, 50/60 Hz
