C-17

Item Name

O.M

General

User

Defaults

C M

Transferred Data Length * 4 h

Para Switch Authority * Unprotected

Parameter Switch * *

 When [Para Switch Authority] is set to

[Protected]: Unselected

 When [Para Switch Authority] is set to

[Unprotected]: Selected

SpO

Tone * Mode 1

Nurse

Call

Signal Type ** Continuous

Contact

Type

* Normally Closed

Alm Lev * * High, Med, Low

Alarm Cat. * * Phys., Tech.

Default Chapter9
- Table of Contents9
1 Safety19
- Safety Information19
- Equipment Symbols22
2 The Basics25
- Monitor Description25
  - Intended Use25
  - Applied Parts25
- Front View26
- Side View28
  - Umec1028
  - Umec12/Umec1529
- Rear View30
- Display Screen31
- Quickkeys33
3 Basic Operations37
- Installation37
  - Unpacking and Checking37
  - Environmental Requirements38
- Getting Started39
  - Turning Power on39
  - Starting Monitoring39
- Disconnecting from Power40
- Using Keys40
- Using the Touchscreen41
- Setting the Screen41
- Using the On-Screen Keyboard42
- Using the Main Menu43
- Changing General Settings44
- Setting Parameters46
  - Switching the Parameters On/Off46
  - Accessing the Parameters Menu47
- Operating Modes47
4 Managing Patients51
- Discharging a Patient51
  - Auto Discharging a Patient after Monitor Power off51
  - Manually Discharging a Patient52
- Admitting a Patient52
  - Auto Admitting a Patient52
  - Manually Admitting a Patient53
- Managing Patient Information53
- Transferring Patient Data Via USB Drive54
- Connecting to a Central Monitoring System57
5 Managing Configurations59
- Introduction59
- Entering the [Manage Configuration] Menu60
- Setting Default Configuration60
- Saving Current Settings61
- Editing Configuration61
- Deleting a Configuration62
- Transferring a Configuration63
- Loading a Configuration63
- Restoring the Latest Configuration Automatically64
- Modifying Password64
6 User Screens65
- Tailoring Your Screens65
- Viewing Minitrends66
  - Having a Split-Screen View of Minitrends66
  - Setting Minitrends67
- Viewing Oxycrg67
- Viewing Other Patients68
- Understanding the Big Numerics Screen71
7 Alarms73
- Alarm Categories73
- Alarm Levels74
- Alarm Indicators74
- Alarm Tone Configuration77
- Understanding the Alarm Setup Menu79
- Pausing Alarms85
- Switching off All Alarms86
- Resetting Alarms87
- Latching Alarms88
- Testing Alarms89
- Using Care Group Alarms89
- When an Alarm Occurs90
8 Monitoring ECG91
- Introduction91
- Safety91
- Preparing to Monitor ECG92
- Understanding the ECG Display96
- Changing ECG Settings97
- About ST Monitoring101
- About Arrhythmia Monitoring106
- About Qt/Qtc Interval Monitoring110
- About HR Analysis113
- ECG Relearning114
  - Initiating an ECG Relearning Manually114
  - Automatic ECG Relearning114
- 12-Lead ECG Monitoring (for Umec12/Umec15)115
  - Entering the 12-Lead ECG Monitoring Screen115
  - Extending the Rhythm Lead Waveform Area116
- Troubleshooting116
9 Monitoring Respiration (Resp)119
- Introduction119
- Safety Information119
- Understanding the Resp Display120
- Placing Resp Electrodes120
- Choosing the Respiration Lead122
- Changing the Apnea Alarm Delay122
- Changing Resp Detection Mode122
- Changing Resp Wave Settings123
- Setting RR Source123
- Setting Alarm Properties124
- Switching Resp Measurement On/Off124
10 Monitoring PR125
- Introduction125
- Setting the PR Source125
- Selecting the Active Alarm Source126
- QRS Tone126
11 Monitoring Spo127
- Introduction127
- Safety128
- Applying the Sensor128
- Changing Spo Settings129
- Measurement Limitations131
- Troubleshooting131
12 Monitoring NIBP133
- Introduction133
- Safety134
- Measurement Limitations134
- Measurement Methods135
- Setting up the NIBP Measurement135
- Understanding the NIBP Numerics138
- Making NIBP Analysis139
- Changing NIBP Settings139
13 Monitoring Temp141
- Introduction141
- Safety141
- Making a Temp Measurement141
- Understanding the Temp Display142
- Setting the Temperature Unit142
14 Monitoring IBP (for Umec12/Umec15)143
- Introduction143
- Safety143
- Zeroing the Transducer144
- Setting up the Pressure Measurement145
- Understanding the IBP Display146
- Changing IBP Settings147
- Troubleshooting149
15 Monitoring Cardiac Output (for Umec12/Umec15)151
- Introduction151
- Understanding the C.O. Display151
- Influencing Factors152
- Setting up the C.O. Measurement152
- Measuring the Blood Temperature156
- Changing C.O. Settings156
  - Setting the Temperature Unit156
  - Setting Alarm Properties156
16 Monitoring Carbon Dioxide (for Umec12/Umec15)157
- Introduction157
- Safety157
- Measurement Limitations158
- Understanding CO Display158
- Measuring CO159
  - Making a CO Measurement159
  - Zeroing the CO Module161
- Changing CO Settings162
- Calibrating the CO Module164
17 Freezing Waveforms165
- Viewing Frozen Waveforms165
- Unfreezing Waveforms166
- Recording Frozen Waveforms166
18 Review167
- Accessing Respective Review Windows167
- Reviewing Graphic Trends167
- Reviewing Tabular Trends169
- Reviewing Events170
- Reviewing Waveforms172
19 Calculations175
- Introduction175
- Dose Calculations176
- Hemodynamic Calculations178
  - Performing Calculations178
  - Entered Parameters178
- Understanding the Review Window180
20 Recording181
- Using a Recorder181
- Overview of Recording Types182
- Starting and Stopping Recordings182
- Setting up the Recorder183
- Loading Paper184
- Removing Paper Jam185
- Cleaning the Recorder Printhead185
21 Printing187
- Printer187
- Connecting a Printer187
- Setting up the Printer188
- Starting Report Printouts188
- Stopping Reports Printouts188
- Setting up Reports189
- Printer Statuses190
  - Printer out of Paper190
  - Printer Status Messages191
22 Other Functions193
- Analog Output193
- Exporting the Log193
- Transferring Data193
  - Data Export System193
  - Transferring Data by Different Means194
- Nurse Call195
- Network Connection196
23 Batteries199
- Overview199
- Battery Guidelines199
- Battery Maintenance200
- Battery Recycling201
24 Care and Cleaning203
- General Points203
- Cleaning204
- Disinfection205
- Sterilization205
25 Maintenance207
- Regular Inspection207
- Maintenance and Testing Schedule208
- Checking Monitor and Module Information209
- Calibrating ECG209
- NIBP Tests210
  - NIBP Leakage Test210
  - NIBP Accuracy Test211
- CO Tests212
- Calibrating the Touchscreen214
- Electrical Safety Tests214
26 Accessories215
- ECG Accessories215
- Spo 2 Accessories218
- NIBP Accessories219
- Temp Accessories220
- IBP Accessories (for Umec12/Umec15)221
- Accessories (for Umec12/Umec15)221
- Others223
- Power Supply Specifications226
- Physical Specifications227
- Hardware Specifications227
- Data Storage229
- Wireless Network230
- Measurement Specifications230
B EMC and Radio Regulatory Compliance241
- Emc241
- Radio Regulatory Compliance246
100 C Default Configurations249
- Parameters Configuration249
- Routine Configuration260
- User Maintenance Items263
D Alarm Messages267
- Physiological Alarm Messages267
- Technical Alarm Messages269
E Electrical Safety Inspection275
- Power Cord Plug275
- Device Enclosure and Accessories276
- Device Labelling276
- Protective Earth Resistance277
- Earth Leakage Test277
- Patient Leakage Current278
- Mains on Applied Part Leakage278
- Patient Auxiliary Current279
F Symbols and Abbreviations281
- Symbols281
- Abbreviations283
