Mindray uMEC12 Operator's Manual

2-3
(7)
If no menu is displayed on the screen, pressing it will enter the main menu. If there is a
menu displayed on the screen, pressing it will close that menu.
(8) Battery LED
 On: when the battery is installed and the AC source is connected.
 Off: when no battery is installed or the installed battery is malfunction, or no AC
source is connected when the patient monitor is power off.
 Flash: when the patient monitor operates on battery power.
(9) AC power LED
It turns on when AC power is connected.
(10) Power On/Off LED
It turns on when the patient monitor is on and turns off when the patient monitor is off.
(11) Knob
Rotate the Knob clockwise or anti-clockwise. With each click, the highlight jumps to the
neighboring item. When you reach your desired item, press the Knob to select it.

Mindray uMEC12 Specifications

General

Type	Patient Monitor
Display	12.1-inch color TFT
ECG	3-lead
SpO2	Yes
NIBP	Yes
Respiration	Yes
Temperature	Yes
Battery	Rechargeable lithium-ion
Networking	Ethernet
Parameters	ECG, SpO2, NIBP, Respiration, Temperature
Connectivity	Ethernet
Battery Life	Up to 4 hours
Power Supply	100-240 VAC, 50/60 Hz
