393
Kaleido-X
User’s Manual
From iControl to Multiviewer
From Multiviewer to/from Remote Control Panel
The following ports, used for communications to/from RCP-200 and Kaleido-RCP2 control
panels, are open by default on all Kaleido-X systems:
HTTP 8080 TCP
8082 TCP Internal communication
8083 TCP Internal communication
8084 TCP Internal communication
8085 TCP Internal communication
8086 TCP Internal communication
8087 TCP Used for debugging purposes
8090 TCP Web service
32769 TCP filenet-rpc
5120 UDP On multicast 230.8.8.9 for RCP2
7572 UDP On multicast 230.8.8.8 for “keep-alive”
(heartbeat)
7571 UDP For “keep-alive” (heartbeat)
Service Port
Transpo
rt
Notes
Java RMI 32768–
65535
TCP Remote Method Invocation (client/server
communication). Dynamic Allocation of ports.
Required for communication between client
and Application Server. This range can be
restricted to match specific security
requirements. A minimum of 4000 ports
should be allocated.
Service Port Transport Notes
RCP2 5120 TCP Used to listen for Kaleido-X discovery packets
10000 TCP For RCP2 protocol
10001 TCP For RCP2 protocol
5120 UDP On multicast 230.8.8.9 for RCP2 protocol
5121 UDP For RCP2 protocol
HTTP 80 TCP Used by the RCP-200 to obtain information
from the multiviewer’s system database
13000 TCP Used by the RCP-200 to control the
multiviewer via the gateway
Service Port Transport Notes
