125
Kaleido-X
User’s Manual
Calibrating Dolby E Audio Metadata
To calibrate audio metadata
1 In the main window, click the System tab, and then click Description/Calibrations on
the second-level tab bar.
A hierarchical list representing the current system appears.
2 In the list, expand the multiviewer whose inputs you wish to calibrate.
3 Expand the appropriate input, and then click Dolby E selection.
4In the Properties tab, select the AES pairs (among Embedded audio 1 to Embedded
audio
8) associated with the two Dolby E programs to be decoded, from the two lists:
Dolby
E selection 1 and Dolby E selection 2.
Notes
• The KMV-3901/3911 and Kaleido-IP do not support extraction of Dolby E
metadata.
• Dolby E decoding can be enabled by purchasing the Dolby E option. In the
case of a Kaleido-X multiviewer model, one license is needed per input
card.
See Enabling Options on page 411.
• Dolby E decoding is not yet supported on the Audio Bridge Terminal
(ABT).
