Miranda Kaleido-X User Manual

338
Tally Interface Devices
Key Concepts
Key Concepts
Optional Drivers for Controlling Tally Interface Devices from the
Multiviewer
Optional drivers are available to extend your Kaleido-X system with the ability to control
tally interface devices such as the ones listed in the tables below. Contact your sales
representative for details.
Detailed Directions
Configuring Serial Tally Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 338
Ross Video Production Switcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 340
Sony Production Switcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 345
Kahuna Production Switcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 348
Kayak Production Switcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 354
Kayenne Production Switcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 360
Zodiak Production Switcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 368
Serial Port Test Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 375
Configuring Serial Tally Systems
This section covers the configuration of the Kalypso, Andromeda, Serial to TCP/IP
Dispatcher and TSL serial devices, which can be added to a multiviewer system to receive
Production Switchers
Company Device/System
Thomson/Grass Valley Kayenne, Kalypso, Zodiak, KayakDD, Kayak SD/HD, DD35, XtenDD
HD/SD series
Ross Synergy series
Snell & Wilcox Kahuna
Sony DVS-9000, MVS-8000, MFS-2000
UMD Controllers
Company Device/System
TSL UMD Controller (serial, TCP/IP or UDP/IP)
Thomson/Grass Valley Andromeda UMD Controller
Image Video TSI-1000 Tally System Interface (requires option from Image Video)
Automation Systems
Company Device/System
Encoda (Harris) D-Series Playout Automation
Sundance Digital Fastbreak NXT Automation (requires option from Sundance Digital)
