Administration and Servicing
Assigning an IP Address to Each Device in Your System
To log on to a Kaleido-X room from the RCP-200
1 On an RCP-200 with an active connection to the network, press the LIST button.
All devices, and Kaleido-X rooms, detected by the RCP-200 appear on the left screen.
Kaleido-X rooms are listed in the form [multiviewer name]\[room name].
If a room belongs to a cluster system, its name appears once for each of the member
multiviewers (e.g. if two multiviewers, KX1 and KX2, are configured as a cluster, and
ROOM1 includes displays fed by both multiviewers, then both KX1\ROOM1 and
KX2\ROOM1 will be listed. To determine the one you should select, review the
following:
• Has the RCP user configuration you wish to use been replicated on every member
of the cluster (see
Replicating RCP Users Across a Cluster System, on page 86)?
• Do you need to control an external router whose configuration is available only
from one or some specific members of the cluster?
• Does your system configuration include actions that were configured only on one
or some specific members of the cluster?
• Do you need to control a timer from the monitor wall in a cascade room?
If any of the above elements is available only from one or some specific members, then
make sure you select the room name prefixed with the appropriate multiviewer name.
In the case of a cascade room, unless you remember which multiviewer you were
connected to when you added the timer you need to control, you will have to proceed
by trial and error.
2 Touch the room you wish to access (press the DOWN or UP soft keys to scroll the list as
needed).
The list of users assigned to this room appears on the right-hand screen.
3 Touch the user name under which you wish to log on, enter your password, and then
touch LOG IN.
The following message appears on the right-hand screen: PLEASE SELECT A ROUTER
FROM THE LEFT-HAND SCREEN, prefixed with the name of the multiviewer that
appeared before the room name you selected in
step 2.
4 In the list on the left-hand screen, touch the KX Router logical router associated with the
same multiviewer (you can see the multiviewer name, its IP address, and the size of that
particular KX Router).
• On a Kaleido-X16-D, the HDMI outputs from each of the Output modules
are assigned to ROOMX16.
• On a Kaleido-X16-S, the HDMI output is assigned to ROOMX16.
• On a KMV-3901/3911, Kaleido-XQUAD, or Kaleido-XQUAD-DUAL, the
HDMI outputs are assigned to ROOM1.
• On a Kaleido-IP, the multiviewer outputs are assigned to ROOM.
• On a Kaleido-MX, or Kaleido-Modular-X, the HDMI outputs are assigned to
ROOM1.
Note: By default, the user “Admin” has no password.
