283
Kaleido-X
User’s Manual
4On the File menu, click Save.
Assigning Room Layouts to a Kaleido-RCP2 User’s Presets
To assign a room layout to a Kaleido-RCP2 user’s preset button
1 In the main window, click the RCP users tab, and then select the user for whom you
wish to configure the remote control panel’s preset buttons, from under the
appropriate room in the hierarchical list.
2 For each Kaleido-RCP2 preset button, click the corresponding box in the Properties
pane, and then select the appropriate layout from the list.
Assigning a Full Screen Layout to an RCP User
To assign a full screen layout to an RCP user
1 In the main window, click the RCP users tab, and then select the user for whom you
wish to configure the remote control panel’s FULL SCREEN button, from under the
appropriate room in the rooms hierarchical list.
Notes
• The “Admin” user name cannot be modified.
• An asterisk (*) will appear beside the RCP user in the main window if any
of the user properties are modified. The asterisk will disappear when the
changes are saved.
• The message “Cannot find reference” indicates that a full screen layout,
full screen zone, or layout associated with a Room or RCP user has been
deleted.
Note: If no layout is specified for this user preset, the layout that has been
selected for this preset in the room’s preferences will apply. It will appear in
gray in the Preset [n] box.
See Setting Room Preferences on page 279.
