Mircom PRO-2000 Series - Table 35: X2 Panel Standby Current Consumption - Main Power Supply

Appendix A - Battery Calculations
94
Standby current consumption of PRO-2000,
X2 panels Main power supply (28V nominal)
System Component
Standby Current
(amps)
Qty Total
LCD card (X0) (with RS-422) 0.278 X =
LCD card (X2) 0.251 X 1 = 0.251
LCD on board RS-232 module 0.063 X =
LCD card user defined LED (local or X0) 0.0022 X =
LCD expander card (Local or X0) 0.056 X =
LCD expander card (local or X0) LED 0.0022 X =
Mimic driver module (local or X0) 0.046 X =
Mimic driver module (local or X0) LED 0.0022 X =
ADI card 0.177 X =
ADI driver module 0.054 X =
Addressable devices (excluding ACDI) 0.00022 X =
Addressable sensors in alarm 0.010 X =
Isolator modules 0.00042 X =
ADI card OUTPUT supervision current - X =
ADI card OUTPUT activated output 0.0113 X =
SI card 0.204 X =
SI card input supervision current 0.0035 X =
SI card input short circuit current 0.0225 X =
SO card 0.036 X =
SO card OUTPUT supervision current - X =
SO card activated OUTPUT 0.0175 X =
Communication card 0.095 X =
Comm. Card on board RS-232 module 0.063 X =
Total Standby current (add this total to Table 34)
The total standby current must not exceed 1.5 Amperes
Main power supply (28V nominal)
Table 35: X2 Panel Standby Current Consumption - Main Power Supply
