Mircom PRO-2000 Series - Figure 17: X0 S, Installation Layout

PRO-2000 Installation and Operation Manual
25
7.16" [181.97mm]
90°
29.68" [753.92mm]
46.76" [1187.60mm]
21.00" [533.40mm]
23.10" [586.74mm]
1.20" [30.48mm]
22.20" [563.88mm]
24.00" [609.60mm]
0.90" [22.86mm]
Figure 17: X0S, Installation Layout
