PRO-2000 Installation and Operation Manual
29
7.16" [181.97mm]
21.00" [533.40mm]
1.20" [30.48mm]
23.10" [586.74mm]
46.76" [1187.60mm]
28.20" [716.28mm]
0.90" [22.86mm]
30.00" [762.00mm]
90.00°
29.68" [753.92mm]
Figure 21: X0E, Installation Layout with Power Supply and Batteries
