Mircom PRO-2000 Series - Figure 14: X6 M, Installation Layout

PRO-2000, X6 SERIES - S/B/E/M
20
7.16" [181.97mm]
90°
29.68" [753.92mm]
46.76" [1187.60mm]
23.10" [586.74mm]
1.20" [30.48mm]
21.00" [533.40mm]
41.00" [1041.40mm]
39.20" [995.68mm]
0.90" [22.86mm]
Figure 14: X6M, Installation Layout
