PRO-2000 Installation and Operation Manual
17
7.16" [181.97mm]
90°
29.68" [753.92mm]
46.76" [1187.60mm]
23.10" [586.74mm]
1.20" [30.48mm] 21.00" [533.40mm]
0.90" [22.86mm]
28.20" [716.28mm]
30.00" [762.00mm]
Figure 11: X6S, Installation Layout
