SI Card
SI card in slot ## missing A SI card is missing in the specified slot.
SI card in slot ## failed
Specified SI card not responding. This fault may be due to hardware or to the
presence of a wrong card in the specified slot.
SI card in slot ## bad isolated power Specified SI card isolated power supply is not functioning.
SI card in slot ## Ground fault Ground fault detected on the specified SI card.
SI card in slot ## config error Specified SI card has an invalid configuration.
SI card in slot ## A/d #1 failed test
The first analog to digital converter in the specified slot failed the initialization test.
Channels 1 to 11 are not available.
SI card in slot ## A/d #2 failed test
The second analog to digital converter in the specified slot failed the initialization test.
Channels 12 to 22 are not available.
SI card in slot ## A/d #3 failed test
The third analog to digital converter in the specified slot failed the initialization test.
Channels 23 to 32 are not available.
SI card in slot ## SPI failed test Specified SI card is faulty.
SI card slot ##-L## Isol. Power = ## Vcc The isolated voltage is under 21 VDC
Table 33c: Card Trouble (continuation)
