PRO-2000 Installation and Operation Manual
63
9
(+)
CIRCUIT SUPERVISED AND POWER-LIMITED
MODULE
AND VOLTAGE LIMITED TO 12V MAX.
CURRENT LIMITED TO 230 MICRO AMPS MAX
TERMINALS 6 & 7 AND 8 & 9 ARE
NOTES:
(+)
7
(-)
1
(-)
6
(+)
2
(-)
8
M500M MONITOR
LPX+
loop
(loop mode)
connections
LPX-
addressable
To ADI card
LPY-
LPY+
DEVICE
NEXT
FROM LAST MODULE/DETECTOR
SHIELDED, TWISTED PAIR
POWER-LIMITED CIRCUITS
TO
Figure 48: 2 Wire Class A Initiating Circuit Configuration of Monitor Module
