Mircom PRO-2000 Series - Figure 22: X0 M Installation Layout with Power Supply and Batteries

PRO-2000 X0 Series - S/E/M
30
7.16" [181.97mm]
90.00°
29.68" [753.92mm]
0.90" [22.86mm]
39.20" [995.68mm]
41.00" [1041.40mm]
1.20" [30.48mm]
23.10" [586.74mm]
46.76" [1187.60mm]
21.00" [533.40mm]
Figure 22: X0M Installation Layout with Power Supply and Batteries
