8 - 36

8.8 CF Card

8.8.2 CF card inserting/removing method with CF card interface of GOT

3 Close the cover of the CF card interface. Set the CF card access switch to ON.

When using other than the GT155 When using the GT155

ACCESS

OFF ON

ACCESS

OFF ON
