8 - 38
8.8 CF Card
8.8.2 CF card inserting/removing method with CF card interface of GOT
CF card eject button
For the following GOTs, after opening the cover of the CF card interface, raise the
CF card eject button.
• GT1585-S, GT1575-S: Hardware version B (April, 2005) or earlier
• GT1575-V, GT1565-V: Hardware version D (April, 2005) or earlier
3 Push the CF card eject button of the GOT to lift the CF card and remove it.
Precautions for removing the CF card
1. While the CF card access LED is on, do not install/remove the CF card or power
off the GOT.
To do so may cause data corruption or malfunction.
2. When ejecting the CF card, support it by hand since it may pop out.
Failure to do so may cause a fall of the CF card leading to failure or damage of
the card.
3. Do not install/remove the CF card while downloading the monitor data or other
data by the RS-232 transmission.
To do so may cause a faulty communication of the GT Designer3 or GT
Designer2 and the data cannot be downloaded normally.
When using other than the GT155 When using the GT155
To Next Page
