14.11 Operator Information Management
14.11.3 Function setting
14 - 57
9
UTILITY FUNCTION
10
COMMUNICATION
INTERFACE
SETTING
11
DISPLAY AND
OPERATION
SETTINGS
12
CLOCK SETTINGS
AND BATTERY
STATUS DISPLAY
13
FILE DISPLAY AND
COPY
14
GOT SELF CHECK
15
CLEANING OF
DISPLAY SECTION
16
MAINTENANCE
TIME NOTIFICATION
SETTING
When [External auth (general)] or
[Fingerprint authentication] is
selected, the check box for
[Operator name + password] is
displayed.
If the check box is selected, the
login is also enabled with
[Operator name + password].
(c) Touch [Password expiration
date], and then the Password
expiration date edit dialog box is
displayed. Input the expiration
date.
When the input is completed,
touch the key.
(d) Initial position input
Set the initial position input (byte
count) of external authentication
ID from among the data read
from the external authentication
device.
(e) Valid byte count input
Set the valid byte count for
external authentication ID.
(Only available when the external
authentication (general) is set as
the authentication method.)
4 Touch the button after all items are
input, and then the dialog box shown left is
displayed and the input setting is saved.
5 Touch the button without touching the
button, and then the dialog box
shown left is displayed.
OK
To Next Page
