Appendix 6.2 For GT10
GT Designer2 Version 2.43V or later is applicable to GT1020.
GT Designer2 Version 2.58L or later is applicable to GT1030.
GT Designer2 Version 2.90U or later is applicable to GT105 .
GT Designer2 Version 2.90U or later is applicable to GT104 .
1 Added GOT main unit
2 Added connection types
: Applicable : N/A - : Applicable (from the first version)
Target Models
Version of GT
Designer2
Version of OS
GT1020-LBD, GT1020-LBD2, GT1020-LBL 2.43V -
GT1020-LBDW, GT1020-LBDW2, GT1020-LBLW 2.58L -
GT1030-LBD, GT1030-LBD2 , GT1030-LBDW, GT1030-LBDW2 2.58L -
GT1055-QSBD, GT1050-QBBD 2.90U -
GT1045-QSBD, GT1040-QBBD 2.90U -
Item Description
Version of GT
Designer2
Version of OS
GT
105 /
104
GT
1030
GT
1020
Direct
connection to
CPU
Supporting connection to FX3G series 2.90U
Standard monitor OS [01.10.**]
Communication driver
MELSEC-FX[01.06.**]
Computer link
connection
Supporting connection to A series PLC 2.82L
Standard monitor OS [01.09.**]
Communication driver
AJ71C24/UC24[01.04.**]
-
CC-Link
connection (Via
G4)
Supporting connection to CC-Link (Via G4) 2.73B
Standard monitor OS [01.07.**]
Communication driver
CC-Link(G4)[01.00.**]
-
GOT multidrop
connection
Supporting the GOT multidrop connection 2.96A
Standard monitor OS [01.11.**]
Communication driver
Multidrop(Host) [01.11.**]
Multidrop(Slave) [01.11.**]
Microcomputer
connection
Supporting the data formats of Format 1 and
Format 2.
2.47Z
Standard monitor OS [01.02.**]
Communication driver
Computer[01.02.**]
--
MODBUS /
RTU connection
Supporting MODBUS /RTU connection
2.96A
Standard monitor OS [01.12.**]
MODBUS/ RTU [01.07.**]
OMRON PLC
connection
Supporting connection to OMRON PLC 2.47Z
Standard monitor OS [01.02.**]
Communication driver
OMRON SYSMAC [01.02.**]
--
KEYENCE PLC
connection
Supporting connection to KEYENCE PLC 2.73B
Standard monitor OS [01.07.**]
Communication driver
KEYENCE KV-700/1000[01.00.**]
-
Supporting connection to KV-3000 and KV-5000 2.77F
Communication driver
KEYENCE KV700/1000 [01.03.**]
-
(Continued to next page)
