TROUEILESHOOTING
I
Rear window washer does
not operate
I
1 IsfuseNo.‘“;:, : 1
Repair the harness and
t replace the fuse
IS 12 V indicated between the
Correct the connector or repair
0.3-L wire and ground &hen a
test probe is inserted from
No
the back of the rear window
washer motor?
Yes
Does the washer function
when a test probe is inserted
from the back of the rear
No
c
window washer motor and
the 0.3-WB wire is grounded?
Yes
Does the washer motor func-
A broken harness between Correct the connector or repair
tion when a test probe is
the rear window washer the harness
inserted from the back of No
motor and the rear wiper
the rear window wiper and
c and washer switch, br a
t
washer switch connector and
poor connector connection
the 0.3-WB wire is grounded?
Yes
SEE NEXT PAGE
8-58
