5 - 334 WiNG 5.5 Access Point System Reference Guide
Figure 5-215 Device Overrides - Advanced Profile MINT screen - IP (Add)
25. Set the following Link IP parameters to complete the MINT network address configuration:
IP Define or override the IP address used by peer access points for interoperation when
supporting the MINT protocol.
Routing Level Use the spinner control to define or override a routing level of either 1 or 2.
Listening Link Specify a listening link of either 0 or 1. UDP/IP links can be created by configuring a
matching pair of links, one on each end point. However, that is error prone and doesn’t
scale. So UDP/IP links can also listen (in the TCP sense), and dynamically create
connected UDP/IP links when contacted.
Port To specify a custom port for MiNT links, select this option and use the spinner control
to define or override the port number from 1 - 65,535.
Forced Link Select this option to specify the MiNT link as a forced link. This setting is disabled by
default.
Link Cost Use the spinner control to define or override a link cost from 1 - 10,000. The default
value is 100.
Hello Packet Interval Set or override an interval in either Seconds (1 - 120) or Minutes (1 - 2) for the
transmission of hello packets. The default interval is 15 seconds.
