MR TAPCON 230 basic User Manual

7 Functions and settings
136 TAPCON® 230 basic 2117246/02 EN © Maschinenfabrik Reinhausen 2012
7.4.3.1 Assigning function to inputs (GPIs)
You can activate the inputs as follows:
 Statically using signal statuses
The input signal must be continually present (status: high level).
 Dynamically using pulses
A pulse (rising edge) is needed at the input. The input signal must change
its status from "Low" to "High". If you are using a pulsed input, you can
trigger the assigned function in parallel, e. g. via the control system and at
buttons connected to the inputs.
You can recognize pulsed inputs from the preceding "P:". The note "Warning:
P = pulsed inputs" is displayed on the screen.
You can assign one of the following functions to each of the digital inputs
(GPIs 1...6):
Function Description
Off No function selected.
Remote/Local Define Remote/Local operating mode.
Signal on: "Remote" operating mode active.
Signal off: "Local" operating mode active.
Blocking Block automatic regulation.
Quick Tap
Activate high-speed return (deactivate T1/T2) (page
96).
Trip MPS Input for "MPS has been tripped" feedback.
Motor running Input for "Motor running" feedback.
Desired value 2 Activate desired value 2.
Desired value 3 Activate desired value 3.
Blk U raise Block tap-change operations (raise).
Blk U lower Block tap-change operations (lower).
P: DV 1 Activate desired value 1.
P: DV 2 Activate desired value 2.
P: DV 3 Activate desired value 3.
Table 40 Functions for digital inputs (GPIs 1...6)
