6 Functions and settings
Maschinenfabrik Reinhausen 2014110 2374092/04 ENTAPCON® 260
Symbols
Figure 70: Time plotter symbols
1 Move time axis back 4 Select values to set
2 Move time axis forward 5 Decrease set values by one
unit
3 Increase set values by one
unit
Desired/actual voltage value display
Figure 71: Desired/actual value
1 Set desired voltage value dis-
play
3 Actual voltage value display
2 Actual voltage value display 4 Set desired voltage value dis-
play
