3 Product description
Maschinenfabrik Reinhausen 2014 272374092/04 EN TAPCON® 260
Figure 17: AN card
Control voltage supply
An additional non-regulated control voltage of 60 V DC can be created with
the AC card if your system does not have external DC voltage as the signal
voltage for the device's digital inputs. Depending on device configuration,
one of the following two variants can be fitted:
▪ AC230: 230 V AC input voltage
▪ AC115: 115 V AC input voltage
CAUTION
Risk of injury from increased output voltage
Slight loading of the AC card may result in the output voltage increasing to
up to 85 V DC.
► Only wire card when not energized.
The output performance of the AC card is limited. The generated DC volt-
age can be used only for the control inputs of the device.
Figure 18: AC230 card
