Muratec F-315 Field Engineering Manual

3-6
Machine Parameter 013
Switch
Initial
Setting
Adjust Usage/Comments
7 1
6 0
5 0
4 1
3 0
2 0
1 0
0 1
Leading edge document
margin adjustment (ADF)
Adjusts the leading edge
margin from Document
Sensor 2 (DS2) to the start of
scanning the position.
1 step = 2 / 600 dpi
(0.0847 mm)
Note: These values
are factory set and should
not be adjusted unless
instructed by a Muratec
technical representative.
Switch 76543210 Settings
127 steps 01111111 +10.76 mm
:
00100000 +2.71 mm
:
00010000 +1.36 mm
:
00001000 +0.68mm
:
00000000 15.6 mm
:
10001000 –0.68 mm
:
10010000 –1.36 mm
:
10010001 –1.44 mm Å Initial setting
:
10100000 –2.71 mm
:
–127steps 11111111 –10.76 mm
Machine Parameter 014
Switch
Initial
Setting
Adjust Usage/Comments
7 0
6 0
5 0
4 0
3 1
2 0
1 1
0 0
Trailing edge document
margin adjustment (ADF)
Adjusts document feed after
the trailing edge of a
document passes Document
Sensor 2 (DS2).
1 step = 2 / 600 dpi
(0.0847 mm)
Note: These values
are factory set and should
not be adjusted unless
instructed by a Muratec
technical representative.
Switch 76543210 Settings
127 steps 01111111 +10.76 mm
:
00100000 +2.71 mm
:
00010000 +1.36 mm
:
00001010 +0.08 mm Å Initial setting
:
00001000 +0.68mm
:
00000000 15.6 mm
:
10001000 –0.68 mm
:
10010000 –1.36 mm
:
10100000 –2.71 mm
:
–127steps 11111111 –10.76 mm
