Muratec F-315 Field Engineering Manual

3-5
Machine Parameter 011
Switch
Initial
Setting
Adjust Usage/Comments
7 0
6 0
5 0
4 0
3 0
2 0
1 0
0 0
Adjustment of the scanning
stretching and squeezing for
ADF.
(Horizontal)
The plus setting stretches the
image data and the minus
setting squeezes it.
Each setting changes by
0.1%
Note: These values are
factory set and should not be
adjusted unless instructed by
a Muratec technical
representative.
Switch 76543210 Settings
00001111 +1.5 %
:
00001000 +0.8 %
:
00000100 +0.4 %
:
00000010 +0.2 %
00000001 +0.1 %
00000000 0 % Å Initial setting
10000001 –0.1 %
10000010 –0.2 %
:
10000100 –0.4 %
:
10001000 –0.8 %
:
10001111 –1.5 %
Machine Parameter 012
Switch
Initial
Setting
Adjust Usage/Comments
7 1
6 0
5 0
4 0
3 1
2 1
1 0
0 1
Adjustment of the scanning
stretching and squeezing for
ADF.
(Vertical)
The plus setting squeezes
the image data and the minus
setting stretches it.
Each setting changes by
0.1%
Switch 76543210 Settings
00001111 +1.5 %
:
00001000 +0.8 %
:
00000001 +0.1 %
00000000 0 % Å Standard
10000001 – 0.1 %
:
10000100 –0.4 %
:
10001000 –0.8 %
:
10001101 –1.3 % Å Initial setting
:
10001111 –1.5 %
