3-68
Memory Switch 15 – Transmission
Switch
Initial
Setting
Adjust Usage/Comments
7 0 Program individual autodialer
attributes
0: No
1: Yes
Allows individual setting of memory switches 10 as
attribute 1, 11 as attribute 2, 12 as attribute 3 and
13 as attribute 4 when one–touch and speed dial
locations are programmed. (Refer to page 3-84 for
settings.)
6 0 Factory use only
5 0 Factory use only
4 0 Factory use only
3 0 Factory use only
2 0 Sending RTC signal when
transmission is canceled
0: Yes
1: No
RTC signal is sent at the end of the transmission.
When set at “0”, the machine will send the RTC if
the transmission is canceled. No error will occur.
When set at “1”, an error will occur because RTC
will not be sent at the end of a canceled
transmission.
1 1 Cancel redial if T.4.1 or T.4.4
error occurs
0: Yes
1: No
When set at “0”, if a T.4.1 or T.4.4 error occurs, the
machine will not retry the transmission.
0 1 Action after EOR signal
0: Continue
1: Discontinue
Sets action after receiving PPR four times at 2400
bps.
Memory Switch 16 – Transmission
Switch
Initial
Setting
Adjust Usage/Comments
7 0 Factory use only
6 0 Factory use only
5 0 Factory use only
4 0 Factory use only
3 1 Additional data on TTI
transmit
0: No
1: Yes
When set at “0”, the transmission of the additional
data (time, the number of pages, file number, etc)
is disabled.
Note: This switch is available only when Memory
switch 012, bit 4 and/or Memory switch 13, bit 5 is
available.
2 1 Subscriber ID transmit
0: No
1: Yes
When set at “0”, the transmission of the subscriber
ID is disabled.
Note: This switch is available only when Memory
switch 12, bit 4 and/or Memory switch 13, bit 5 is
available.
1 1 TTI (name) transmit
0: No
1: Yes
When set at “0”, the transmission of the name that
is stored in the unit is disabled.
Note: This switch is available only when Memory
switch 12, bit 4 and/or Memory switch 13, bit 5 is
available.
0 0 Factory use only
Memory Switch 17 ∼ 19 – Factory use only
