3-69
Memory Switch 20 – Reception
Switch
Initial
Setting
Adjust Usage/Comments
7 0 Data error rate
0: 10%
1: 20%
Determines the allowable number of erred lines out
of total lines received in a document.
6 0 Pause one second after
sending CED
0: No (75 ms)
1: Yes (1 sec)
A 2100 Hz CED signal disables echo suppression in
some telephone equipment. When set to "1", the
machine pauses one second after sending CED,
which allows echo suppression to restart. This may
help with problematic overseas reception.
5 0 Factory use only
4 0 Factory use only
3 1
2 1
1 0
0 1
Receive speed (kbps)
Maximum receive speed may be slowed to compensate for poor phone lines.
2.4 4.8 7.2 9.6 12 14.4 16.8 19.2 21.6 24 26.4 28.8 31.2 33.6
0 0 0 0 0 0 0 0 1 1 1 1 1 1
0 0 0 0 1 1 1 1 0 0 0 0 1 1
0 0 1 1 0 0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 0 1 0 1 0 1
Memory Switch 21 – Reception
Switch
Initial
Setting
Adjust Usage/Comments
7 0 Not used
6 0 DIS “inch” declaration
0: No
1: Yes
5 0 Paper size limitation
0: No limit
1: 3m
This will limit the paper length of the received
document. Setting this bit to “1”, the paper will be
cut when the length reached to 3m.
4 0 T1 timer
0: 35 sec
1: 20 sec
Adjusts the T1 time–out. After the machine dials the
remote machine’s phone number, it begins sending
CNG and waits this amount of time before
disconnecting the line.
3 1 Print image data when post
message is not received after
receiving RTC signal
0: No
1: Yes
If the received document includes the RTC, the
machine prints the data even though the following
protocol is not succeeded.
2 0 DIS/DTC Extend field
Transmit
0: Yes
1: No（Tx until Bit No.24 of
DIS/DTC）
Setting this switch to “1” will disable ITU– T
superfine mode.
1 0
0 1
G3 echo receive
Adjusts the delay between detection of training/TCF and sending of CFR.
100 ms 500 ms 800 ms 1200 ms
Switch 1 0 0 1 1
Switch 0 0 1 0 1
Memory Switch 22 ––– Factory use only
