EFA-200/-300 9 Device data memory
9-3
Matrix block Sect. 7.1.3 XA = 0
YA = 0
ZA = 1
XB = 10
YB = 10
ZB = 3
Current position in block Sect. 7.1.3 XN = 0
YN = 0
ZN = 1
Ranking Sect. 7.1.3 XYZ
MODE menu (operating modes)
Operating mode Sect. 6 Field Strength
Operating mode: Field Strength
Detection mode Sect. 6.1.3 RMS
Frequency range Sect. 6.1.5 Broadband filter
5 Hz to 2 kHz
Bandpass filter from selection list Sect. 8.7.2 50 Hz
Stop band filter from selection list Sect. 8.7.2 50 Hz
Mode: Spectrum FFT / Harmonic Analysis
Normalization (meas. range) Sect. 6.3.2 OFF
Detection mode Sect. 6.3.3
Sect. 6.4.3
ACT RMS
Frequency range Sect. 6.3.5 5 Hz...2 kHz
Fundamental frequency Sect. 6.4.5 50 Hz
Frequency axis scaling (X SCALE) Sect. 6.3.7.1 5 Hz...2 kHz
Measured value axis scaling (Y SCALE) Sect. 6.3.7.2 100 dB
Reference value, measured value (Y POS) Sect. 6.3.7.2 0 dB
Parameter Section Value
Table 9-1 Factory Default Setup
