Annex D: Data export format EFA-200/-300
D-4
• Data set type AUTO (differences with respect to data set type NORMAL)
• Data set type MATRIX (differences with respect to data set type
NORMAL)
Spectrum FFT mode
• Data set type VECTOR
Data set type D A = AUTO
Index in data set N Number
Time step STEP hh:mm:ss
Data set type D M = Matrix
Index in data set N Number
X-Index X Number
Y-Index Y Number
Z-Index Z Number
Parameter Code Values
Data set number MEM# Number
Data set type D V = Vector
Index in data set N Number
Probe used PROBE INT_PRB = Internal probe
EXT_PRB_1 = Probe 100 cm²
EXT_PRB_2 = Probe 3 cm
Meas. axis CHN ALL = isotropic
X, Y, Z = Single axis
Mode MODE FFT = Spectrum FFT
Limit curve STANDARD Te xt
Date DATE yy-mm-dd
Time TIME hh:mm:ss
Frequency range F_RANGE 5 Hz…2 kHz
40 Hz…32 kHz
Resolution DF[HZ] Number
Detection mode DET ACT = ACT RMS
AVG = AVG RMS
PEAK = Vector Peak
