EFA-200/-300 Annex D: Data export format
D-5
Harmonic Analysis mode
• Data set type LIST
Display mode MAX LIVE
MAX
Spectral value, unit VALUE [x]
T = Tesla
G = Gauss
V/m
Number
Validity indicator VALID OK
!A = Computation incomplete
!O = Overdriven
Parameter Code Values
Data set number MEM# Number
Data set type D L = List
Probe used PROBE INT_PRB = Internal probe
EXT_PRB_1 = Probe 100 cm²
EXT_PRB_2 = Probe 3 cm
Meas. axis CHN ALL = Isotropic
X, Y, Z = Single axis
Mode MODE HAR
Date DATE yy-mm-dd
Time TIME hh:mm:ss
Detection mode DET ACT = ACT_RMS
AVG = AVG_RMS
PEAK = Vector Peak
Display mode MAX LIVE
MAX
Frequency, fundamental F1 [HZ] Number
Measured value,
fundamental, unit
VALUE [x]
T = Tesla
G = Gauss
V/m
Number
Harmonic factors K2 [%]
…
K9 [%]
Number
Total harmonic factor KT [%] Number
