6 Operating modes EFA-200/-300
6-32
No. Function
1 Field quantity, here the B field
2 Measurement axis,
here without footnote: ISOTROPIC
3 Measured value axis
4 Graphical display of the measured values
5 Frequency axis scaled as an index (multiple of the
fundamental frequency selected in F4)
6 Display field F4: Display of the selected fundamental
frequency
7 Display field F3: Display of the selected display mode
8 Display field F2: Display of the selected detection mode
9 Display field F1: Display of the selected measurement
range
10 Validity indicator:
• No icon: Internal measured value computation
complete.
• “■”: Note
Internal measured value computation is underway. The
displayed measured value has not yet reached its final
value.
• “ “: Warning
Measurement range violation
The selected measurement range is unsuitable for the
field being measured.
11 Display of the operating state
• “ “: Run state
Measurement is underway. The spectrum is
continuously recorded and displayed.
• “ “: Stop state:
Recording of further measured values has halted.
Table 6-8 Screen evaluation for Harmonic Analysis mode
