NEC Electra Elite IPK II System User Manual

Document Revision 4C Electra Elite IPK II
2 - 1032 Universal Slots
 There are 32 common ports in the IPK II that are shared by all three cabinets.
 Each Universal Slot is a 16-port slot.
 The Basic Port Package does not limit the number of slots. It only limits the number of
ports.
 The DTI/PRI ETUs can be programmed as a 4/8/12/16/20/24 port Fractional T1/PRI.
(Version 1500 or higher is required and PRG 10-39-01 must be Enabled).
 AP/ISA Slot is not used in the IPK II.
 If trying to assign an ETU which would excede the maximum number of ports for the Basic
Port Package you do not get an error, but it does not let you program the related programs.
 The available interface cards and maximum capacities for Universal Slots with the Electra
Elite IPK II system are shown in Table 2-41 Maximum System Capacities for Station
Interface ETUs, Table 2-42 Maximum System Capacities for Trunk Interface ETUs and
Table 2-43 Maximum System Capacities for Application Interface ETUs.
Table 2-41 Maximum System Capacities for Station Interface ETUs
Station Interface
Units
Description
Maximum Capacities
Notes
Basic Port
Package
Expanded
Port
Package
CMS(2)/(4)-U( ) ETU 2- or 4-Port Digital Voice Mail System 1 1 Notes 1~4, 6
CNF(8)-U( ) ETU 8-port Conference Unit. This Multiline
Conference Bridge allows any
intercom user or outside party calling
to a port of the CNF(16)-U20 ETU to
join or make a multiparty Conference
Call. Each ETU supports one 8-party
conference or two 4-party
conferences regulated by a switch
setting.
This ETU is installed in slots S1~S8
in the B64-U20 KSU. The system
recognizes this ETU as an SLI(8)-U( )
ETU. This ETU shares the total
number of station ports in the system.
2 2 Notes 1, 4, 6
