Electra Elite IPK II Document Revision 4C
K-CCIS – IP with PVA 2 - 661
K-CCIS – IP with PVA
Description
This feature provides the benefits and additional feature compatibility of Key-Common Channel
Interoffice Signaling (K-CCIS) between multiple systems including NEAX PBX systems connected
together over a Data Communication IP Network (Intranet). Voice signals and common signaling data
from/to the distant offices are converted into IP Packets and transmitted through the Data IP Network.
When using the IP (K-CCIS) to NEAX (Point-to-Multipoint) feature, both voice and data communication
lines are integrated into one network and communication costs can be reduced.
This feature is available between Electra Elite IPK II systems and NEAX PBX systems. When
connecting to a NEAX system, IPT cards are used and must be installed.
The following K-CCIS features are available with the IP (K-CCIS) to NEAX (Point-to-Multipoint) feature:
Call Forwarding – All Calls – K-CCIS
Call Forwarding – Busy/No Answer – K-CCIS
Call Transfer – All Calls – K-CCIS
Calling Name Display – K-CCIS
Calling Number Display – K-CCIS
Enhancements
This feature was added with Version 1100.
Version 1500 or higher:
A 4-port license registration allows users to add CCISoIP Ports in increments of four (4, 8, 12, 16, 20 or
24).
The CCISoIP web server has a new HTTP page to display the network statistics based on values entered
in PRG 84-06.
Version 1600 or higher:
A remote K-CCIS user can transfer a call directly to an ACD Pilot number. Prior to this release, this type
of transfer was not allowed.
Version 2000 or higher:
Supports station numbers to be assigned by the 10s group for 4-digit station numbers, 100s group for
5-digit, 1,000s group for 6-digit station numbers, and 10,000s for 7-digit station numbers.
Supports the Combined functionality of a MG16 and K-CCIS over IP and SIP Stations/trunks on one card.
