NEC Electra Elite IPK II System User Manual

Electra Elite IPK II Document Revision 4C
Single Line Telephones, Analog 500/2500 Sets 2 - 885
Related Features
Single line telephone users have access to the following features:
Data Communications
APA and APR modules can be used with multiline terminals to provide an analog port.
Refer to the individual features for additional descriptive, programming and operational information.
Programming
 10-03-01 ETU Setup – Terminal Type (B1) for ESI PKG
Program all on-premise 500/2500 type single line telephones with circuit type 2. Set the DIOPU
trunk to type 1 when trunks should be defined for off-premise extension (OPX) use.
 10-03-03 ETU Setup – For SLI PKG – Transmit Gain Level (S-Level)
10-03-04 ETU Setup – For SLI PKG – Receive Gain Level (R-Level)
Assign transmit and receive levels for 500/2500 type single line telephones.
 10-09-01 DTMF and Dial Tone Circuit Setup
If the system has 2500 type (DTMF) single line extensions, allocate at least one circuit for
analog extension DTMF reception (entry 0 or 1).
Use the following as a guide when allocating DTMF receivers:
 In light traffic sites, allocate one DTMF receiver for every 10 devices that use them.
 In heavy traffic sites, allocate one DTMF receiver for every five devices that use them.
 Speed Dialing  Account Codes  Alarm
 Automatic Route Selection  Barge-In  Call Forwarding
 Call Forwarding with Follow Me  Call Forwarding/DND Override  Call Waiting/Camp-On
 Callback  Central Office Calls, Answering  Central Office Calls, Placing
 Conference  Department Calling  Department Step Calling
 Directed Call Pickup  Do Not Disturb  Door Box
 Flash  Forced Trunk Disconnect  Group Call Pickup
 Hold  Intercom  Handsfree Answerback/Forced
Intercom Ringing
 Last Number Redial  Line Preference  Meet Me Conference
 Meet Me Paging  Meet Me Paging Transfer  Message Waiting
 Night Service  Off-Hook Signaling  Paging
 PBX Compatibility  Pulse to Tone Conversion  Ringdown Extension
 Save Number Dialed  Selectable Display Messages  Toll Restriction
 Transfer  Trunk Queuing and Camp-On  Voice Mail
 Voice Over  Warning Tone for Long Conversation
