NEC Electra Elite IPK II System User Manual

Electra Elite IPK II Document Revision 4C
D
term
IP Gateway System 2 - 407
D
term
IP Gateway System
Description
The D
term
IP Gateway system converts traditional voice traffic and its accompanying signaling for call
setup and networking to IP for transport across a managed IP network. The system allows users at
branch offices or telecommuters to take advantage of the rich feature set of the company central site
Key Telephone System as though they were connected locally without loss of functionality. Traditional
voice traffic (plus call setup and networking signaling) travel from the KTS to the Gateway where they
are converted to IP packets that are shipped to a 10 Mb (Gateway) or 10 Base-T/100 Base-TX (Gateway
II) Ethernet LAN port. They are then picked up by the enterprise router and sent to the corporate WAN.
At the branch office, the local router receives the WAN signals and feeds them to the local 10 Base-T/
100 Base-TX LAN. From there they reach the D
term
IP Branch unit that converts the IP packets back to
standard (TDM) voice signals for distribution to attached D
term
Series E/Electra Elite telephones. The
D
term
IP Branch supports up to 12 voice circuits. When the remote site is a telecommuter at home or
only a few users, the remote IP/TDM conversion is performed by a D
term
IP Adapter that fits easily on the
bottom of a standard D
term
Series E telephone.
This system:
 supports circuit-/packet-based Networks.
 allows mix and match IP-capable EXTender clients up to eight or 12 users.
 connects to the digital-line side of the Electra Elite IPK II KTS.
 allows virtual configuration, management, and troubleshooting of EXTender clients from a central
location.
 allows synchronous transmission.
 supports an asynchronous Terminal Adapter (TA).
 allows encrypted user name and password on each port.
 supports call suspend mode on ISDN line with Asynchronous TA.
 supports IP Precedence and DiffServ QoS mechanisms.
 allows choice of network topologies and variable compression rates.
