Facsimile CO Branch Connection 2 - 443
F
Facsimile CO Branch Connection
Description
The Electra Elite IPK II system provides branch connection of locally provided facsimile
machines to CO/PBX lines. Additional dedicated CO/PBX lines are not required for a
facsimile to operate. The facsimile shares the last CO/PBX line on the COI(4)-U( ), or
COIB(4)-U( ) ETU through the Main Distribution Frame (MDF) where the CO line is
connected from Telco.
Conditions
 The Electra Elite IPK II systems require a COI(4)-U( ), or COIB(4)-U( ) ETU to
connect a facsimile in branch to a direct CO/PBX line.
 Connection of the facsimile machine does not require extra system ports.
 The Electra Elite IPK II systems cannot distinguish between an incoming
facsimile call and a CO/PBX call. Ringing assignments should be turned off for
fax lines.
 A facsimile call terminating at the CO/PBX line where the Fax Branch Unit is
connected is automatically answered by the Fax Machine. Delayed Ringing Line
assignment to stations for Fax Branch Line are Recommended.
 When the facsimile is in use, the Fax Branch CO/PBX line can be used as an
outside line.
 Code restriction does no apply to outgoing calls from the Fax machine.
Default Settings
None
System Availability
Terminals
None
