NEC Electra Elite IPK II System User Manual

Document Revision 4C Electra Elite IPK II
2 - 444 Facsimile CO Branch Connection
Required Component(s)
COI(4)-U( ) ETU or COIB(4)-U( ) ETU
Related Features
None
Programming
 14-02-14 Analog Trunk Data Setup – Loop Start/Ground Start
0 = Loop Start
1 = Ground Start
 14-05-01 Trunk Group
Trunk Ports = 1~200
Trunk Groups = 0~100
 22-01-04 System Options for Incoming Calls – DIL No Answer Recall Time
Time – 0~64800 sec. (default is 0)
 22-04-01 Incoming Extension Ring Group Assignment
Maximum: eight digits (up to 32 extensions per group)
Default: Extensions 101~108 (first 8 ports) ring for incoming Ring Group 1 calls. No other
extensions ring for incoming Ring Group 1 calls.
 22-05-01 Incoming Trunk Ring Group Assignment
0 (No Setting)
1~8 or 001~100 Incoming Group (Default is 1)
102 (In-Skin/External Voice Mail)
 22-08-01 DIL/IRG No Answer Destination
0 = No Setting
001~100 = Incoming Group (Default is 1)
102 = In-Skin/External Voice Mail
103 = (Centralized Voice Mail)
Operation
None
