NEC Electra Elite IPK II System User Manual

Electra Elite IPK II Document Revision 4C
Internal Hub 2 - 523
Default Setting
None
System Availability
Terminals
None
Required Components:
HUB(8)-U( ) ETU
Related Features
None
Programming
 85-01-01 Hub(8) LAN Setup – Auto Negotiation
Enable (1)/Disable (0) Auto Negotiation. When enabled; Link Speed, Duplex and MDI/MDIX
settings are negotiated with the other connected device. Default is 0.
 85-01-02 Hub(8) LAN Setup – Link Speed
Set the Link Speed to 10Mbps (0) or 100Mbps (1) if Auto Negotiation is disabled in PRG
85-01-01. Default is 1.
 85-01-03 Hub(8) LAN Setup – Half Duplex/Full Duplex
Set the Duplex to Half (0) or Full (1) if Auto Negotiation is disabled in PRG 85-01-01. Default is
1.
 85-01-04 Hub(8) LAN Setup – Auto MDI/MDIX
When PRG 85-01-01 is enabled, Auto MDI/MDIX functions. Auto MDI/MDIX (Media Dependent
Interface/Media Dependent Interface Crossover) enables a switch port to sense the appropriate
transmit/receive pairs of an Ethernet cable. Default is 2.
 85-01-05 Hub(8) LAN Setup – Back Pressure, Half Duplex
When Enabled (1), a switch applies back pressure to a half-duplex ingress port while an output
queue is congested. (Only applicable when PRG 85-01-01 is disabled and PRG 85-01-03 is
half-duplex.) Default is 0.
