Electra Elite IPK II Document Revision 4C
IP Trunk – (SIP) Session Initiation Protocol 2 - 573
IP Trunk – (SIP) Session Initiation Protocol
Description
The Electra Elite IPK II Voice over IP Trunk Card SIP package sends real-time voice over the corporate
LAN or WAN. The voice from the telephone is digitized and then put into frames to be sent over a
network using Internet protocol.
Using VoIP equipment at a gateway (a network point that acts as an entrance to another network), the
packetized voice transmissions from users in the company are received and routed to other parts of the
company intranet (local area or wide area network) or they can be sent over the Internet using CO lines
to another gateway.
The IAD(8)-U10 ETU – SIP is an optional interface that can provide IP trunks and Tie Lines. It can
operate in the following modes:
COI
COID
DID
TLI
DTI
Depending on the requirements and resource allocation in the LAN/WAN/Internet, the IAD(8)-U10
ETU - SIP can be configured to use any of the following voice compressions:
G.711 -Law – Highest Bandwidth
G.729 (a) – Most often used
The IAD(8)-U10 ETU – SIP can be assigned in any of the following configurations:
A 2-port TLI(2)-U10 ETU
A 4-port DID(4)/COI(4)/COID(4)-U10 ETU
An 8-port COI(8)/COID(8)-U10 ETU
A DTI ETU using eight channels that can be installed in interface slots supporting these ETUs.
The LAN/WAN or Internet connection is provided by a 10 Base-T/100 Base-TX Ethernet.
The ETU operating mode can be configured per ETU, but not per port.
