NEC Electra Elite IPK II System User Manual

Document Revision 4C Electra Elite IPK II
2 - 572 IP Trunk – H.323 Protocol
System Availability
Terminals
All Multiline Terminals
Required Component(s)
IAD(8)-U10 ETU – H.323 package
Related Features
None
Programming
 10-03-01 ETU Setup
 11-01-01 System Numbering
 14-02-01 Analog Trunk Data Setup – Signaling Type (DP/DTMF)
At default, PRG 14-02-01 is set to 2 (DTMF). For the IAD trunks this must be set for Dial Pulse
[either 0 (10PPS) or 1 (20PPS)].
 14-05-01 Trunk Group – Trunk Group Number
 44-02-01
through
44-02-03 Dial Analysis Table for ARS/F-Route Access
 44-05-01 ARS/F-Route Table – Trunk Group Number
IAD(8)-U( ) assigned as DTI is allocated 24 trunk ports, but can use only the first eight ports.
The remaining trunk ports should be assigned to Trunk Group 0.
 44-05-09 ARS/F-Route Table – Maximum Digit
Operation
None
