Electra Elite IPK II Document Revision 4C
Code Restriction 2 - 237
 21-06-06 Toll Restriction Table Data Setup – Permit Code Table
Program codes in the Permit Code Tables.
 21-06-07 Toll Restriction Table Data Setup – Deny Restriction Table
Program codes into the Restrict Code Tables (200 codes per table maximum).
 21-06-08 Toll Restriction Table Data Setup – PBX Access Code
The system allows up to four tables for PBX access codes. PBX Access Codes can have up to
two digits, using 0~9, #,
 and LINE KEY 1 (don’t care). Refer to the PBX Compatibility feature
for the specifics.
 21-21-01 Toll Restriction Class for Trunks (Seized Trunk Basis Setting) – Restriction Class
Toll restriction class for trunks. For each trunk, assign a Class restriction Class for each Day/
Night Service Mode.
 34-01-05 E&M Tie Line Basic Setup – System Toll Restriction
Enable (1)/Disable (0) the ability for Tie Line calls to follow the system Toll Restriction entries in
PRG 21-05-01 through PRG 21-05-13. If disabled, Tie Line Code Restriction is determined by
PRG 21-05-13.
 34-08-01 Toll Restriction Data for E&M Tie Lines
Define the Toll Restriction data for E&M Tie Lines. This data must be defined if Tie Line Code
Restriction is enabled in Program 21-05-13.
Operation
To place a trunk call if your system is Code Restricted:
1. Place call normally.
 If your Code Restriction Class does not allow the number you dial, the call is cut off.
