NEC Electra Elite IPK II System User Manual

Electra Elite IPK II Document Revision 4C
Code Restriction Override 2 - 247
Programming
 11-11-34 Service Code Setup (for Setup/Entry Operation) – Temporary Toll Restriction Override
If required, change the service code (775) for Temporary Toll Restriction Override.
 11-11-36 Service Code Setup (for Setup/Entry Operation) – Toll Restriction Override
If required, change the service code (663) for Toll Restriction Override.
 20-08-06 Class of Service Options (Outgoing Call Service) – Toll Restriction Override
Enable (1)/Disable (0) an extension user ability to use Temporary Toll Restriction Override.
 21-01-07 System Options for Outgoing Calls – Toll Restriction Override Time
Set the Toll Restriction Override Time (0~64800 seconds). After dialing the Toll Restriction
Override code, the system removes Toll Restriction for this time.
 21-07-01 Toll Restriction Override Password Setup
Assign Toll Restriction Override codes to extensions. Each code must have four digits, using
any combination of 0~9, # and
. Each extension can have a separate code, or many extensions
can share the same override code.
 21-14-01 Walking Toll Restriction Password Setup – User ID
Enter the Walking Toll Restriction Override User ID codes (six digits) into tables. Up to 500
different override codes can be entered.
 21-14-02 Walking Toll Restriction Password Setup – Walking Toll Restriction Class Number
Enter the Walking Toll Restriction Class of Service (1~15) to be used for each table number
assigned in PRG 21-14-01.
 35-02-01
through
35-02-18 SMDR Output Options
Assign the output condition for the printer or PC. If the data is set to 1 (output), the symbol of the
call prints as POTA and the password table number is printed as W/@@@ (@@@ is the three
digit table number) in the Account Code area.
Operation
To temporarily override a restricted extension Code Restriction:

You can override restriction for only one call at a time.
1. At the multiline terminal, press Speaker.
- OR -
At single line telephone, lift the handset.
2. Dial 775.
3. Dial the 4-digit Code Restriction Override code.
