Electra Elite IPK II Document Revision 4C
D
term
IP Gateway System 2 - 409
The Gateway power supply and cables should be installed away from high power/high RF
noise devices such as computers, fans, fluorescent ballast, or power supplies.
Good wiring practices are required. Do not run wires across devices such as fluorescent
lights, computers, or air conditioners to avoid introducing noise in the modems.
The distance between the PBX/KTS and the Gateway unit must not exceed 500 feet.
When 5-, 6-, or 7-digit station numbers are used, this feature is not available.
Default Setting
None
System Availability
Terminals
DTU/DTP/DTR Multiline Terminals
DTP-32DE-1 for home environment
Required Component(s)
Components include the following:
Electra Elite IPK II KTS with one ESI port for each Branch port and IP Adapter
Gateway unit
Branch unit and/or IP Adapters with total ports not exceeding the number of ports
supported by the Gateway unit
Power Cord
RS-530 cable
2 RJ-21 50-pin cables to connect Gateway to DTS and Branch to punch block – connectors
required include a female connector to attach to D
term
IP, and a male connector to attach to
the KTS.
Punch blocks that can cross-connect the D
term
IP Gateway to the KTS and D
term
telephones to the branch locations.
Installation hardware for Gateway and Branch units
System Administrator’s Guide
Quick Installation Guide
