Document Revision 4C Electra Elite IPK II
2 - 480 Handset Mute
 80-01-02 Service Tone Setup – Basic Tone Number
(Default: 0).
Refer to Table 2-27 Service Tone Setup, Program 80-01-02 on page 2-480.
Operation
While talking on a terminal handset:
1. Press MIC (DTH/DTR terminals only).
- OR -
2. Press Feature + dial 1.
- OR -
3. Press the Handset Transmission Cut-Off key (PRG15-07-01; Key 40 or SC 751 Key Code 40).
62
Splash Tone 3 (Mute)
3Basic 2 0
6
1
1
8 (-12dB)
8 (-12dB)
63
EXT SPK Ring-back Tone
0Basic 210
0
10
30
32 (0dB)
32 (0dB)
64
Music on Hold (MOH)
0 0 0 0 32 (0dB)
Table 2-27 Service Tone Setup, Program 80-01-02
Item
No.
Item Repeat Count
02
Basic Tone Number
1~33
0 = No Tone
33=Default Time Slot
03
Duration Count
1~255
(100~25500ms)
04
Gain Level (dB)
1~63
(-15.5 ~ +15.5)
Table 2-26 Service Tone Setup, Program 80-01-01
Service
Tone
No.
Service Tone
Repeat
Count
Unit
Count
Basic
Tone No.
Duration
Gain Level
(dB)
