NEC Electra Elite IPK II System User Manual

Document Revision 4C Electra Elite IPK II
2 - 948 T1 Trunking (with ANI/DNIS Compatibility)
 34-09-07 ANI/DNIS Service Options – Routing on ANI/DNIS Error
Determine how the system handles an ANI/DNIS call if a data error is detected in the incoming
data string (0 = Play busy tone to caller, 1 = Route the caller to the ring group specified in
Program 25-03).
(default: 1)
 34-09-08 ANI/DNIS Service Options – Routing When Destination Busy or No Answer
Determine how the system handles an ANI/DNIS call if destination is busy or does not answer (0
= Play busy or ringback tone to caller, 1 = Route the caller to the ring group specified in Program
25-04).
(default: 0)
 34-09-09 ANI/DNIS Service Options – Calling Number Address Length
When Item 1=0 (ANI/DNIS receive format is the address), use this option to specify the address
length. The choices are from one to eight digits.
(default: 7)
 34-10-01 Digits Delete for T1 ANI Assignment
Define the number of digits (0~9) to delete from the information element received from Telco.
Requires Version 1.10 or higher CPUII Software.
(default: 2)
Operation
Refer to the operation for the following features:
 Central Office Calls, Answering
 Central Office Calls, Placing
 Direct Inward Dialing (DID)
 Tie Lines
