2 - 58 Chapter 2
Chapter 2 - Blade Installation and Startup
2.6.1.1 Indicators, Switches and Connectors
2.6.1.1.1 Switches
The PVAU has the following switches.
● DIP Switch SW1
Reserved for future use.
● RESET Switch SW3
This switch allows the technician to reset the PVAU blade without having to
remove and insert it again in the UX5000 chassis.
2.6.1.1.2 Connectors
● Ethernet Connector
The PVAU has a single 10/100 MPS Ethernet connector. The port has Auto-MDIX
(Auto-Medium Dependent Interface Crossover) giving users the ability use either
a straight-through Ethernet cable or a crossover Ethernet cable. A crossover
cable is not required for direct connection to a PC.
The Ethernet Interface setting allows for manual configuration of the Ethernet port
mode/speed from the Web Interface. This can be set to operate in the following
port speed and duplex mode: 10MB/Full Duplex, 10MB/Half Duplex, 100MB/Half
Duplex, 100MB Full Duplex, Auto-Negotiate.
● Serial Connector
A 10-pin header (J2) provides access to a serial terminal on the PVAU blade.
The serial connector is used for debug operations only.
2.6.1.2 Installing the PVAU Blade:
1. Insert the desired CompactFlash into the PVAU blade.
2. Intall the PVAU into any available slot.
Refer to the Multimedia Conference Server Installation Manual, P/N 0913215, or PVAU NAT
Traversal instructions, P/N 0913106, for complete details on this blade.
