Chapter 4 - Terminals and Optional Equipment
Chapter 4 4 - 43
SECTION 4-15
TERMINAL ADAPTERS
4.15.1 Using Adapters
The UX5000 digital keysets and IP terminals provide 3 types of optional interfaces/adapters: handset units,
adapters for the bottom of the terminals, and line key kits. Each UX5000 terminal may have multiple optional
adapters installed, depending on the type of terminal and the adapter used. These adapters provide the
terminal different capabilities, depending on the adapters installed.
● Only the ILPA, ADA and PSA Adapters can be used on the IP terminals.
● 16-Button DLS (16LK)
● ADA - Conversation Recording
● APR - Analog Port Adapter with Ringer
● BCH - Bluetooth Cordless Handset
● BHA - Bluetooth Hub Adapter
● GBA - Gigabit Ethernet Adapter
● PSA - Keyset/IP Terminal Power Failure
When installing or removing the adapters, the terminal should first be unplugged from the system.
Handset Options - Handset Device
● Standard Handset with PSA Built-In Cradle
● Standard Handset with Standard Cradle
● Bluetooth Cordless Handset (BTH) with Cordless Handset RF Cradle (BTC)
✎ The Cordless handset RF Cradle uses both the Handset Option connection and
the Bottom of the Terminal connection (preventing any voice/data devices from
being installed)
Bottom of the Terminal Adapters - Voice/Data Device
● BHA
● ADA
● APR
● GBA
Side Connector - Dedicated Data Devices
● 16-Button DLS
● 60-Button DSS (IP)
If Aspire keysets are connected to the UX5000 system, then these phones will
support the use of the ADA (Conversation Record), APR (Analog Port Adapter),
CTA (RS-232 Serial Interface) and CTU (USB) adapters as well. However, only
for reports and SMDR - TAPI is not available with these units on the UX5000
system. Other adapters are not supported with Aspire Keysets on the UX5000.
