Chapter 2 - Blade Installation and Startup
Chapter 2 2 - 17
2.4.1.2 DSP Resources
The CCPU has 128 channels for the DSP sender with both the base and expansion chassis. There are
32 channels of DSP resources (receivers) provided by the base chassis (only devices connected to the
base chassis can use them). The EXIFU has an additional 64 DSP resources (receivers), however, these
resources can only be used within the expansion chassis (devices connected to the base chassis cannot
use them). These DSP sender and resource channels are used for the following purpose exclusively:
The function of each DSP is as follows:
DSP Sender
● Service Tone Generation
● DTMF Sender
● MF Sender (E911)
● MFC Sender (E1)
DSP Resource
● Call Progress Tone Detection
● DTMF Receiver
● Caller ID Sending
● Caller ID Receiver
● MF Receiver (T1 ANI)
● MFC Receiver (E1)
When the CygniLink feature is used, the resources are split up into zones based on the network ID
number assigned in Program 51-01-01 : CygniLink System Settings - CygniLink System ID.
Base Chassis Expansion Chassis
CCPU DSP Sender 128 channels
DSP Resource 01-32
(Program 10-09)
32 channels -
EXIFU-B1
(not available for the EXIFU-E1)
DSP Resource 97-160
(Program 10-09)
- 64 channels
Note: DSP resources 33~96 are not used (dummy numbers).
DSP Resource Zones
Zone 1 Zone 2 Zone 3 Zone 4 Zone 5
System ID 12345
678910
11 12 13 14 15
16: 17 18 19 20
21 22 23 24 25
26 27 28 29 30
31 32 33 34 35
36 37 38 39 40
41 42 43 44 45
46 47 48 49 50
